• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Input HP	7.2
Style	A,B
Gear Type	Straight Bevel
Service Factor	1
Ratio	1:2
Output RPM	2300
Maximum Input HP	7.2 @ 1150 RPM
Input Diameter (in)	1.000 in
Product Line	Bevel Gear Drives
Product Type	Right Angle
Output Diameter (in)	0.625 in
Series Code	150
Ratio Range	1:2
Input Style	Shaft
Housing Dimensions	(L)6.28125 x (H)4.125 x (W)6.1875
Reduction	Single
Housing Height (in)	4.125 in
Housing Width (in)	6.1875 in
Housing Length (in)	6.28125 in
Output Shaft Direction	Double
Housing Material	Cast Iron
Output Shaft	Shaft
Gear Drive Size	150
Output Torque Rating (in-lb)	195 in/lbs
Output Torque Range (in-lb)	< 250 in lbs in/lbs

General Specifications

UPC	662798004563
Weight	25.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
