• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Input HP	5.4
Ratio	1.80:1
Service Factor	1
Style	A,B
Input Diameter (in)	1.000 in
Output Diameter (in)	1.000 in
Series Code	11
Product Line	Bevel Gear Drives
Product Type	Right Angle
Output RPM	972.2
Maximum Input HP	5.4 @ 1750 RPM
Gear Type	Straight Bevel
Ratio Range	2:1
Input Style	Shaft
Housing Length (in)	6.4375 in
Housing Dimensions	(L)6.4375 x (H)4.59375 x (W)5.71875
Housing Height (in)	4.59375 in
Housing Width (in)	5.71875 in
Reduction	Single
Output Shaft Direction	Double
Output Torque Rating (in-lb)	350 in/lbs
Gear Drive Size	11
Output Torque Range (in-lb)	250 to 500 in lbs in/lbs
Output Shaft	Shaft
Housing Material	Cast Iron

General Specifications

UPC	662798004259
Weight	21.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
