• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Gear Type	Straight Bevel
Input HP	12
Series Code	11
Output RPM	1150
Product Type	Right Angle
Style	C,F
Maximum Input HP	12 @ 1150 RPM
Product Line	Bevel Gear Drives
Input Diameter (in)	1.000 in
Output Diameter (in)	1.000 in
Service Factor	1
Ratio	1:1
Input Style	Shaft
Ratio Range	1:1
Housing Dimensions	(L)6.4375 x (H)4.59375 x (W)5.71875
Housing Height (in)	4.59375 in
Housing Length (in)	6.4375 in
Housing Width (in)	5.71875 in
Reduction	Single
Output Shaft Direction	L or R
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Output Shaft	Shaft
Housing Material	Cast Iron
Gear Drive Size	11
Output Torque Rating (in-lb)	660 in/lbs

General Specifications

UPC	662798004129
Weight	21.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
