• Universal Voltage Sensing With One Connection
• Operating Range: 4-12W
• Fan Packs with One design that fits both 9.5” and 9.8” bolt circle
• 2400 RPM constant speed operation
• Covers upto 400 CFM air flow
• IP66 and IP67 Rating (water-tight,dust-tight and submersible)
• ATEX certified and Ignition-protected component suitable for HVACR Flammable Refrigerant Applications
• UL® Recognized Component
• Cross Reference: FBS12Y4AE4110, 5R027, 5R028, 5R037, 5SME58AAF1031, 5SME58AAF1005, EC5472FP, MD5471, MD5472, 5472, 05471, 05472
• Carton Includes: a.) HILO fan pack, b.) Right angle plug adapter (7.5” long), c.) Installation guide

Nameplate Specifications

Motor Type	Electronically Commutated
Speed	2,400 rpm
Number of Speeds	1
Phase	1
Ambient Temperature	60 °C
UL	Yes
CSA	N

Technical Specifications

Blower Outlet Shape	Round
Motor Enclosure	Totally Enclosed
Blower Outlet Flange	Yes
Bearing Type	Ball
Fan Size	200
Air Flow	400
Voltage Range	90-240 V
Current Range	0.45-0.22 A
Frequency	50-60 Hz
Impeller Type​	Axial
Number of Fan Blades	3
Rotation Direction	Clockwise Opposite Shaft End
Electrical Type	Electronically Commutated Motor
Type of Protection	Automatic
ODE Bearing Type	Metal Shield Ball Bearing
Insulation Class	B
IP Code	IP66/IP67
DE Bearing Type	Sealed Ball Bearing
CE	Y

General Specifications

UPC	818508029283
Weight	3.00 LB
Packaged Length	11.00 IN
Packaged Width	11.00 IN
Packaged Height	6.00 IN
Country of Origin	Mexico
