• Sealed Ball Bearings
• Capacitor Start
• Open Dripproof
• 303 Stainless Steel Shaft
• 50°C Ambient
• UL 1081 Design
• Energy Efficient

Nameplate Specifications

Phase	1
Output HP	2 1/2 Hp
Output KW	1.9 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1
Frame	48Y
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	50 °C
Frequency	60 Hz
Current	11.2 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Thread
Overall Length	14.57 in
Frame Length	10.69 in
Shaft Diameter	0.625 in
Shaft Extension	0.906 in

General Specifications

UPC	786674033277
Weight	32.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
