• Sealed Switch Design
• UL 1081 Design
• 50°C Ambient
• 304 Bearing Shaft End
• 303 Stainless Steel Shaft
• Threaded Shaft
• Capacitor Start-Capacitor Run
• Energy Efficient
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	0.75 Hp
Output KW	0.56 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1
Frame	56J
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	50 °C
Frequency	60 Hz
Current	7.6/3.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	13.57 in
Frame Length	7.63 in
Shaft Diameter	0.625 in
Shaft Extension	2.56 in

General Specifications

UPC	786674032898
Weight	21.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
