• Internally mounted capacitor
• Sealed switch design
• Threaded shaft

Nameplate Specifications

Phase	1
Output HP	1 1/2 Hp
Output KW	1.1 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1.3
Frame	56J
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Efficiency	75.8 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	11.0/22.0 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Threaded
Overall Length	13.87 in
Frame Length	8.06 in
Shaft Diameter	0.625 in
Shaft Extension	2.433 in

General Specifications

UPC	786674032072
Weight	27.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.40.6040
Country of Origin	China
