• Brass current carrying
• Single and two speed
• Continuous filtration of oil
• Electro-zinc encapsulating varnish
• Heavy magnet wire insulation
• Moisture resistant terminal board
• Electro-zinc plated governor parts, dust caps and terminal board cover
• Auto protector

Nameplate Specifications

Phase	1
Output HP	1-1/3 Hp
Output KW	0.75 kW
Voltage	230 V
Speed	1725/1140 rpm
Service Factor	1
Frame	56Z
Enclosure	Open Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.4/3.9 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	4/6
Rotation	Reversible
Mounting	Resilient Base
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	12.09 in
Frame Length	6.69 in
Shaft Diameter	0.625 in
Shaft Extension	2.13 in

General Specifications

UPC	786674054593
Weight	33.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
