• Sealed Ball Bearings
• Capacitor Start-Capacitor Run
• Sealed Switch Design
• 50°C Ambient
• 303 Stainless Shaft
• UL 1081 Design
• 304 Bearing Shaft End
• Threaded Shaft
• Energy Efficient

Nameplate Specifications

Phase	1
Output HP	3.0 Hp
Output KW	2.2 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1.15
Frame	Y56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 15.0-13.3 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	C Face
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Threaded
Overall Length	14.86 in
Frame Length	9.25 in
Shaft Diameter	0.625 in
Shaft Extension	2.53 in

General Specifications

UPC	786674003836
Weight	44.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
