• Sealed Ball Bearings
• Capacitor Start
• Sealed Switch Design
• 50°C Ambient
• 303 Stainless Shaft
• UL 1081 Design
• 304 Bearing Shaft End
• Threaded Shaft

Nameplate Specifications

Phase	1
Output HP	1 Hp
Output KW	0.75 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1.5
Frame	56J
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Efficiency	70.6 %
Ambient Temperature	50 °C
Frequency	60 Hz
Current	9.3/18.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Cap Start Motor
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Thread
Overall Length	14.70 in
Frame Length	8.75 in
Shaft Diameter	0.625 in
Shaft Extension	2.562 in

General Specifications

UPC	786674031785
Weight	26.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.40.6040
Country of Origin	Thailand
