• Energy Efficient
• Low Noise
• Switchless
• E-Coated Main Frame for Superior Corrosion Resistance
• Cool Running for Longer Winding Life
• Sealed Ball Bearings
• 50°C Ambient
• 303 Stainless Steel Shaft
• Hayward Northstar Replacement

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	208-230/115 V
Speed	3450 rpm
Service Factor	1.85
Frame	U56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 6.0-5.5/11.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball Brg
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Thread
Overall Length	13.10 in
Frame Length	7.00 in
Shaft Diameter	0.625 in
Shaft Extension	2.557 in

General Specifications

UPC	786674031044
Weight	31.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.40.6040
Country of Origin	Mexico
