• Two Speed
• Threaded Shaft
• Rigid Base
• Cap Start Low Speed, PSC High Speed
• Energy Efficient
• Open Dripproof
• Sealed Ball Bearings
• 50°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	3.0/.38 Hp
Output KW	2.2 kW
Voltage	230 V
Speed	3450/1725 rpm
Service Factor	1
Frame	56Z
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	50 °C
Frequency	60 Hz
Current	12.0/3.7 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
Number of Speeds	2

Technical Specifications

Electrical Type	Psc Low Speed, Cap Start High Speed
Starting Method	Across The Line
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	13.30 in
Frame Length	8.63 in
Shaft Diameter	0.500 in
Shaft Extension	2.372 in

General Specifications

UPC	786674030887
Weight	34.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
