• Auto protector
• Sealed switch design
• 303 stainless steel threaded shaft

Nameplate Specifications

Phase	1
Output HP	1 1/2 Hp
Output KW	1.1 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1.47
Frame	48Y
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	40 °C
Frequency	60 Hz
Current	12.0 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Multi-Speed Multi-Electrical Types.
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Threaded
Overall Length	19.57 in
Frame Length	8.06 in
Shaft Diameter	0.750 in
Shaft Extension	7.625 in

General Specifications

UPC	786674029409
Weight	31.00 LB
Packaged Length	23.00 IN
Packaged Width	10.00 IN
Packaged Height	9.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
