• All Copper Windings
• Open Dripproof
• 303 Stainless Steel Shaft
• Threaded Shaft
• Sealed Ball Bearings
• 50°C Ambient
• 3 Phase
• Jet Pump
• Square Flange

Nameplate Specifications

Phase	3
Output HP	3.0 Hp
Output KW	2.2 kW
Voltage	208-230/460 V
Speed	3450 rpm
Service Factor	1.15
Frame	Y56Y
Enclosure	Open Drip Proof
Thermal Protection	No Protection
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 10/5 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	3450

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Thread
Overall Length	13.38 in
Frame Length	9.00 in
Shaft Diameter	0.625 in
Shaft Extension	0.906 in

General Specifications

UPC	786674029300
Weight	33.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.52.4000
Country of Origin	Mexico
