• High starting torque on start-up, to achieve a higher starting load required in poultry duty applications.
• High-efficiency design delivers increased energy savings.
• Gasketed conduit box protects wiring from dust entry.
• Resilient or rigid base (as noted).

Nameplate Specifications

Phase	1
Output HP	1 Hp
Output KW	0.75 kW
Voltage	115/230 V
Speed	1725/1425 rpm
Service Factor	1.30
Frame	56
Enclosure	Totally Enclosed Air Over
Thermal Protection	Automatic
Ambient Temperature	40 °C
Frequency	60/50 Hz
Current	9.0/4.5 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	12.65 in
Frame Length	7.69 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in

General Specifications

UPC	786674029140
Weight	42.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
