• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Suitable for use on a VFD, 10:1 variable torque and 2:1 constant torque.
• Class F insulation(as noted) protects motor for a maximum temperature rating.
• 1.15 service factor on sinewave, 1.0 service factor on IGBT power.
• Double sealed ball bearings mechanically locked on shaft end.

Nameplate Specifications

Phase	1
Output HP	5.0 Hp
Output KW	3.7 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1.15
Frame	Y184JM
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	20.0 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Clockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	17.12 in
Frame Length	9.00 in
Shaft Diameter	1.250 in
Shaft Extension	4.28 in

General Specifications

UPC	786674028938
Weight	53.00 LB
Packaged Length	19.00 IN
Packaged Width	12.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
