• OEM Direct Replacement Motor
• 5.6" Diameter - 48 Frame
• Permanent Split Capacitor (PSC); Capacitor Required: 7.5 Mfd-370 Volts (Not Supplied with Motor)
• Thermally Protected
• Open Shaft End End-Frame, Enclosed Lead End End-Frame, Semi-Enclosed Shell, Air Over
• Class B Insulation, 60°C Ambient
• Sleeve Bearing
• 1/2" Diameter Shaft with Double Flat
• 48" Power Leads with Female Spade Terminals, 72" Capacitor Leads with Female Spade Terminals
• Extended Studs Shaft End and Lead End, Mounting Holes in Shell

Nameplate Specifications

Phase	1
Output HP	1/3 Hp
Output KW	0.25 kW
Voltage	208-230 V
Speed	1075 rpm
Service Factor	1.0
Frame	48Y
Enclosure	Open Air Over
Thermal Protection	Automatic
Ambient Temperature	60 °C
Frequency	60 Hz
Current	2.2 A
Duty	Air Over
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor
Starting Method	Across The Line
Poles	6
Rotation	Reversible
Mounting	Extended Studs
Motor Orientation	Vertical Shaft Down
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Frame Material	Rolled Steel
Shaft Type	Double Flat
Overall Length	10.74 in
Frame Length	3.75 in
Shaft Diameter	0.500 in
Shaft Extension	5.5 in

General Specifications

UPC	786674028167
Weight	14.00 LB
Packaged Length	13.78 IN
Packaged Width	6.41 IN
Packaged Height	6.81 IN
HTC	8501.40.4040
Country of Origin	China
