• Ball bearings
• Rigid base

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.25
Frame	48Z
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	40 °C
Frequency	60 Hz
Current	9.6/4.8 A
Duty	Continuous
Insulation Class	A
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start
Starting Method	Across The Line
Poles	2
Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.06 in
Frame Length	6.38 in
Shaft Diameter	0.625 in
Shaft Extension	1.53 in

General Specifications

UPC	786674027702
Weight	23.00 LB
Packaged Length	14.00 IN
Packaged Width	8.00 IN
Packaged Height	8.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
