Nameplate Specifications

Phase	3
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1.15
Frame	56Y
Enclosure	Open Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.5/1.25 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Shaft Extension	5/8 X 1.9 in

General Specifications

UPC	786674027269
Weight	21.00 LB
Packaged Length	13.00 IN
Packaged Width	7.00 IN
Packaged Height	7.00 IN
HTC	8501.51.4040
Country of Origin	Mexico
