• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.

Nameplate Specifications

Phase	3
Output HP	2.0-.50 Hp
Output KW	1.5 kW
Voltage	230 V
Speed	1745/850 rpm
Service Factor	1.15
Frame	56
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.6/2.4 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	N
Number of Speeds	2-1-VT

Technical Specifications

Electrical Type	Polyphase, Induction Type, Multi-Speed
Starting Method	Across The Line
Poles	4/ 8
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	13.06 in
Frame Length	7.25 in
Shaft Diameter	0.875 in
Shaft Extension	2.31 in

General Specifications

UPC	786674055958
Weight	15.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.52.4000
Country of Origin	Mexico
