Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	200-230/460 V
Speed	850 rpm
Service Factor	1
Frame	56Z
Enclosure	Open Air Over
Thermal Protection	Thermally Protected
Efficiency	68 %
Ambient Temperature	70 °C
Frequency	60 Hz
Current	4.5-4.4/2.2 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Poles	8
Rotation	Reversible
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Frame Length	8.65 in
Shaft Diameter	0.625 in
Shaft Extension	6.00 in

General Specifications

UPC	786674077141
Weight	36.50 LB
Packaged Length	17.22 IN
Packaged Width	6.61 IN
Packaged Height	6.61 IN
Country of Origin	Mexico
