• High operating temps, Rated 70°C (158°F) Max Ambient temperature
• Patented Max Guard® insulation system ensures dependable motor life under the adverse thermal and dielectric stresses imposed by the high switching frequencies of PWM medium voltage drives
• The JuggerNaut® Pro condenser fan motor with bearing current protection. BCP™ technology is an internal grounding brush mounted internally on the drive end for servicing when needed
• VCD™ Voltage Change Device enables quick 230V or 460V voltage selection
• Double sealed ball bearings are pre-lubricated with a special formulation for moisture resistance and provide extra-long life
• Automatic reset thermal protector protects against motor overload and automatically resets
• UL® recognized and CSA® certified
• Operational at 208-230/460 V @60HZ. Nameplate image may vary from actual product.

Nameplate Specifications

Phase	3
Output HP	1&0.75 Hp
Voltage	230/460&190/380 V
Speed	850/715 rpm
Service Factor	1.0
Frame	56HZ
Enclosure	Open Air Over
Thermal Protection	Thermally Protected
Efficiency	72 %
Ambient Temperature	70 °C
Frequency	60/50 Hz
Current	5.4/2.7&5.2/2.6 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Line Or Inverter
Poles	8
Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Frame Length	10.15 in
Shaft Diameter	0.625 in
Shaft Extension	6 in

General Specifications

UPC	786674076212
Weight	50.94 LB
Packaged Length	23.00 IN
Packaged Width	10.00 IN
Packaged Height	9.00 IN
HTC	8501.51.6040
Country of Origin	Mexico
