• Automatic reset thermal protector prevents overheating.
• Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
• Vertical/horizontal mounting for proper placement of the fan within airflow.

Nameplate Specifications

Phase	3
Output HP	1 Hp
Output KW	0.75 kW
Voltage	575 V
Speed	850 rpm
Service Factor	1
Frame	56HZ
Enclosure	Open Air Over
Thermal Protection	Thermally Protected
Efficiency	72 %
Ambient Temperature	70 °C
Frequency	60 Hz
Current	2 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Squirrel Cage Induction Run
Starting Method	Line Or Inverter
Poles	8
Rotation	Reversible
Mounting	Bolt-on Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Special Extension
Frame Length	9.65 in
Shaft Diameter	0.625 in
Shaft Extension	6.00 in

General Specifications

UPC	786674076113
Weight	48.43 LB
Packaged Length	23.00 IN
Packaged Width	10.00 IN
Packaged Height	9.00 IN
Country of Origin	Mexico
