• Long lasting with Triple Seal™ protection to prevent water and debris intrustion
• Fast and easy installation with the open and accessible terminal board and wiring compartment
• Premium sealed 203 bearings both ends
• Definitive shaft access (7/16” wrench)
• Voltage change device
• Open dripproof
• Designed for optimal performance and efficiency
• Most durable and economical solution in the market today

Nameplate Specifications

Phase	1
Output HP	2.75 Hp
Output KW	2.1 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1
Frame	56J
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	50 °C
Frequency	60 Hz
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Thread
Overall Length	16.24 in
Frame Length	9.50 in
Shaft Diameter	0.625 in
Shaft Extension	2.56 in

General Specifications

UPC	786674070241
Weight	33.00 LB
Packaged Length	16.63 IN
Packaged Width	10.63 IN
Packaged Height	10.63 IN
Country of Origin	Thailand
