• 60°C Ambient
• Energy Efficient
• Capacitor Start/Capacitor Run
• Sealed Ball Bearings
• UL 1081 Design
• Open Dripproof
• 303 Stainless Steel Shaft
• Hayward Tristar Replacement
• Replaces SP3220Z1BE

Nameplate Specifications

Phase	1
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1.35
Frame	Y56Y
Enclosure	Open Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	60 °C
Frequency	60 Hz
Current	12.0-11.0 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Threaded
Overall Length	14.13 in
Frame Length	9.75 in
Shaft Diameter	0.625 in
Shaft Extension	0.91 in

General Specifications

UPC	786674025234
Weight	38.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
