• Long lasting with Triple Seal™ protection to prevent water and debris intrustion
• Fast and easy installation with the open and accessible terminal board and wiring compartment
• Premium sealed 203 bearings both ends
• Definitive shaft access (7/16” wrench)
• Voltage change device
• Open dripproof
• Designed for optimal performance and efficiency
• Most durable and economical solution in the market today

Nameplate Specifications

Phase	1
Output HP	1.25 Hp
Output KW	0.93 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1
Frame	P56Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	6.6/13.2 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Threaded
Overall Length	13.05 in
Frame Length	8.27 in
Shaft Diameter	0.625 in
Shaft Extension	0.91 in

General Specifications

UPC	786674071408
Weight	21.00 LB
Packaged Length	14.17 IN
Packaged Width	9.13 IN
Packaged Height	9.13 IN
Country of Origin	Thailand
