• Ball bearings

Nameplate Specifications

Phase	3
Output HP	5.0 Hp
Output KW	3.7 kW
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1.15
Frame	Y56Y
Enclosure	Open Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	14.5-14.4/7.2 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	16.32 in
Frame Length	10.38 in
Shaft Diameter	0.875 in
Shaft Extension	2.31 in

General Specifications

UPC	786674056528
Weight	52.00 LB
Packaged Length	19.00 IN
Packaged Width	10.00 IN
Packaged Height	9.00 IN
HTC	8501.52.4000
Country of Origin	Mexico
