• Ball bearings

Nameplate Specifications

Phase	3
Output HP	SPL Hp
Voltage	208-230/460-575 V
Speed	1140 rpm
Service Factor	1
Frame	P56Z
Enclosure	Open Air Over
Thermal Protection	Thermally Protected
Ambient Temperature	70 °C
Frequency	60 Hz
Current	5.5/2.8-3.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Reversible Counterclockwise
Mounting	Round Belly Band
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	15.10 in
Frame Length	9.00 in
Shaft Diameter	0.625 in
Shaft Extension	3.63 in

General Specifications

UPC	786674070517
Weight	44.00 LB
Packaged Length	19.00 IN
Packaged Width	12.00 IN
Packaged Height	10.00 IN
HTC	8501.52.4000
Country of Origin	Mexico
