• Automatic reset thermal protector prevents overheating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
• Vertical/horizontal mounting for proper placement of the fan within airflow.

Nameplate Specifications

Phase	3
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	575 V
Speed	1140 rpm
Service Factor	1
Frame	L56Z
Enclosure	Totally Enclosed Air Over
Thermal Protection	Thermally Protected
Ambient Temperature	60 °C
Frequency	60 Hz
Current	1.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	13.81 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	3.56 in

General Specifications

UPC	786674024947
Weight	32.00 LB
Packaged Length	19.00 IN
Packaged Width	10.00 IN
Packaged Height	9.00 IN
HTC	8501.51.6040
Country of Origin	Mexico
