• Automatic reset thermal protector prevents overheating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
• Vertical/horizontal mounting for proper placement of the fan within airflow.

Nameplate Specifications

Phase	3
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	575 V
Speed	1140 rpm
Service Factor	1
Frame	L56Y
Enclosure	Open Air Over
Thermal Protection	Thermally Protected
Ambient Temperature	60 °C
Frequency	60 Hz
Current	1.25 A
Duty	Continuous Air Over
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Reversible Clockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	16.31 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	6.06 in

General Specifications

UPC	786674024916
Weight	33.00 LB
Packaged Length	19.00 IN
Packaged Width	8.00 IN
Packaged Height	8.00 IN
HTC	8501.51.4040
Country of Origin	Mexico
