• Resilient Base
• Single and two speed

Nameplate Specifications

Phase	3
Output HP	1/2 Hp
Output KW	0.37 kW
Voltage	575 V
Speed	1725 rpm
Service Factor	1.25
Frame	H56
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	.88 A
Duty	Continuous
Insulation Class	A
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Cushion Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	10.07 in
Frame Length	4.13 in
Shaft Diameter	0.625 in
Shaft Extension	1.94 in

General Specifications

UPC	786674059512
Weight	36.00 LB
Packaged Length	15.50 IN
Packaged Width	10.50 IN
Packaged Height	10.00 IN
HTC	8501.51.4040
Country of Origin	Mexico
