• Resilient Base
• Single and two speed

Nameplate Specifications

Phase	3
Output HP	3.0 Hp
Output KW	2.2 kW
Voltage	575 V
Speed	3450 rpm
Service Factor	1.15
Frame	P56HZ
Enclosure	Open Enclosed
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Reversible Counterclockwise
Mounting	Cushion Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	13.81 in
Frame Length	8.00 in
Shaft Diameter	0.875 in
Shaft Extension	2.31 in

General Specifications

UPC	786674024831
Weight	37.00 LB
Packaged Length	16.00 IN
Packaged Width	9.00 IN
Packaged Height	8.00 IN
HTC	8501.52.4000
Country of Origin	Mexico
