• Mechanically locked bearing on shaft end
• Double sealed ball bearings
• 303 stainless steel threaded shaft

Nameplate Specifications

Phase	3
Output HP	1.5 Hp
Output KW	1.1 kW
Voltage	208-230/460 V
Speed	3450/2850 rpm
Service Factor	1.3
Frame	M56J
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.8-5.6/2.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Reversible Clockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Threaded
Overall Length	12.35 in
Frame Length	6.75 in
Shaft Diameter	0.625 in
Shaft Extension	2.60 in

General Specifications

UPC	786674023803
Weight	27.00 LB
Packaged Length	16.00 IN
Packaged Width	9.00 IN
Packaged Height	8.00 IN
HTC	8501.52.4000
Country of Origin	China
