• Reversible
• Cushion ring, no base and C-face
• No protector

Nameplate Specifications

Phase	3
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1.50
Frame	H56CZ
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	50 °C
Frequency	60 Hz
Current	2.7-2.8/1.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	9.25 in
Frame Length	4.13 in
Shaft Diameter	0.625 in
Shaft Extension	1.25 in

General Specifications

UPC	786674022615
Weight	21.00 LB
Packaged Length	14.00 IN
Packaged Width	8.00 IN
Packaged Height	8.50 IN
HTC	8501.52.4000
Country of Origin	Mexico
