• Meets or exceeds all USA mandated efficiencies
• Heavy-duty, rolled steel construction ensures motor durability.
• Continuous air over duty design allows consistent operation at the rated power. specifications
• Double-shielded bearings extend the service life of the motor.

Nameplate Specifications

Phase	3
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1
Frame	X145T
Enclosure	Totally Enclosed Air Over
Thermal Protection	No Protection
Ambient Temperature	65 °C
Frequency	60 Hz
Current	6.1-6.0/3.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	13.31 in
Frame Length	7.50 in
Shaft Diameter	0.875 in
Shaft Extension	2.31 in

General Specifications

UPC	786674056153
Weight	47.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.52.4000
Country of Origin	Mexico
