• NEMA C-Face
• Double sealed ball bearings

Nameplate Specifications

Phase	3
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	200-230/460 V
Speed	1140 rpm
Service Factor	1.25
Frame	J56C
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.0-4.0/2.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Reversible Counterclockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.07 in
Frame Length	5.13 in
Shaft Diameter	0.625 in
Shaft Extension	2.07 in

General Specifications

UPC	786674022097
Weight	28.00 LB
Packaged Length	14.07 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
