• Ball bearings

Nameplate Specifications

Phase	3
Output HP	SPL Hp
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1.15
Frame	56
Enclosure	Open Enclosed
Thermal Protection	Automatic
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.6/1.8 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	N
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase
Starting Method	Across The Line
Poles	4
Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.84 in
Frame Length	6.69 in
Shaft Diameter	0.625 in
Shaft Extension	2 in

General Specifications

UPC	786674020321
Weight	26.00 LB
Packaged Length	15.88 IN
Packaged Width	8.81 IN
Packaged Height	7.81 IN
HTC	8501.52.4000
Country of Origin	Mexico
