• Resilient Base
• Single and two speed

Nameplate Specifications

Phase	1
Output HP	0.5 Hp
Output KW	0.37 kW
Voltage	115 V
Speed	1725 rpm
Service Factor	1
Frame	56Z
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Efficiency	70 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Single Special Extension
Overall Length	11.51 in
Frame Length	7.15 in
Shaft Diameter	0.500 in
Shaft Extension	1.88 in

General Specifications

UPC	786674074843
Weight	25.00 LB
Packaged Length	13.00 IN
Packaged Width	10.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
