• Ball bearings

Nameplate Specifications

Phase	1
Output HP	1/4 Hp
Output KW	0.19 kW
Voltage	115 V
Speed	1140 rpm
Service Factor	1.35
Frame	56
Enclosure	Open Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.9 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Clockwise/Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.07 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in

General Specifications

UPC	786674067913
Weight	25.00 LB
Packaged Length	14.07 IN
Packaged Width	9.55 IN
Packaged Height	10.77 IN
