• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.

Nameplate Specifications

Phase	1
Output HP	1/6 Hp
Output KW	0.13 kW
Voltage	115 V
Speed	1725 rpm
Service Factor	1.35
Frame	48Z
Enclosure	Open Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	Across The Line
Poles	4
Rotation	Counterclockwise Lead End
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Flat
Overall Length	9.78 in
Frame Length	4.81 in
Shaft Diameter	0.500 in
Shaft Extension	2.00 in

General Specifications

UPC	786674067814
Weight	13.00 LB
Packaged Length	14.00 IN
Packaged Width	8.00 IN
Packaged Height	8.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
