• 2-1/4 x 5/8 shaft dimensions
• Single speed

Nameplate Specifications

Phase	1
Output HP	1/8 Hp
Output KW	0.10 kW
Voltage	115 V
Speed	1140 rpm
Service Factor	1.4
Frame	J56CZ
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	3.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Reversible Counterclockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.25 in
Frame Length	5.13 in
Shaft Diameter	0.625 in
Shaft Extension	2.25 in

General Specifications

UPC	786674019905
Weight	19.00 LB
Packaged Length	15.00 IN
Packaged Width	13.00 IN
Packaged Height	10.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
