• NEMA design B
• Energy efficient

Nameplate Specifications

Phase	3
Output HP	1/4 Hp
Output KW	0.19 kW
Voltage	208-230/460 V
Speed	1725 rpm
Service Factor	1
Frame	56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	70 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	1.1-1.1/0.55 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Polyphase, Induction Type, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	10.17 in
Frame Length	5.13 in
Shaft Diameter	0.625 in
Shaft Extension	2.07 in

General Specifications

UPC	786674069658
Weight	20.00 LB
Packaged Length	13.00 IN
Packaged Width	10.00 IN
Packaged Height	10.00 IN
HTC	8501.51.4040
Country of Origin	Mexico
