• UL and CSA Listed, Meeting NEMA MG1 standards.
• Brush holder design provides easy access for motor maintenance.
• Permanent magnet design ensures higher motor efficiency.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Compatible with PWM or SCR type controllers.

Nameplate Specifications

Output HP	1 Hp
Output KW	0.75 kW
Voltage	180 V
Speed	2500 rpm
Service Factor	1
Frame	S56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Current	5 A
Duty	Continuous
Insulation Class	H
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	DC Permanent Magnet
Starting Method	Across The Line
Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	13.82 in
Frame Length	6.47 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in

General Specifications

UPC	786674065445
Weight	33.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
HTC	8501.31.6000
Country of Origin	United States of America
