• Skewed armature for smooth and quiet operation

Nameplate Specifications

Output HP	1/6 Hp
Output KW	0.13 kW
Voltage	230 V
Speed	1140 rpm
Service Factor	1
Frame	34
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Ambient Temperature	40 °C
Current	0.7 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	DC Permanent Magnet
Starting Method	Across The Line
Rotation	Reversible
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Flat
Overall Length	9.82 in
Frame Length	6.06 in
Shaft Diameter	0.500 in
Shaft Extension	1.62 in

General Specifications

UPC	786674065070
Weight	13.00 LB
Packaged Length	14.44 IN
Packaged Width	7.94 IN
Packaged Height	10.88 IN
HTC	8501.31.4000
Country of Origin	United States of America
