• Sealed Ball Bearings
• Capacitor Start-Capacitor Run
• Sealed Switch Design
• 50°C Ambient
• 303 Stainless Shaft
• Energy Efficient
• Meets California Energy Commission Appliance Regulations 2008
• UL 1081 Design
• 304 Bearing Shaft End
• Threaded Shaft

Nameplate Specifications

Phase	1
Output HP	1/2 Hp
Output KW	0.37 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1.6
Frame	56J
Enclosure	Open Drip Proof
Thermal Protection	Automatic
Ambient Temperature	50 °C
Frequency	60 Hz
Current	4.0/8.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	14.70 in
Frame Length	7.63 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674017246
Weight	23.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
