• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Automatic reset thermal protector (as noted) protects against overload.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Interchangeable with most OEM designs.

Nameplate Specifications

Phase	1
Output HP	1/3 Hp
Output KW	0.25 kW
Voltage	115 V
Speed	1725 rpm
Service Factor	1.0
Frame	48Y
Enclosure	Open Enclosed
Thermal Protection	Automatic
Efficiency	55 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.2 A
Duty	Continuous
Insulation Class	B
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase
Starting Method	Across The Line
Poles	4
Rotation	Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Frame Material	Rolled Steel
Shaft Type	Slot
Overall Length	8.63 in
Frame Length	4.94 in
Shaft Diameter	0.625 in
Shaft Extension	0.28 in

General Specifications

UPC	786674017109
Weight	14.00 LB
Packaged Length	11.00 IN
Packaged Width	7.50 IN
Packaged Height	7.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
