• Heavy gauge steel frame and base

Nameplate Specifications

Phase	1
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1.15
Frame	56
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	84.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	16/8.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	14.43 in
Frame Length	6.75 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in

General Specifications

UPC	786674073891
Weight	53.30 LB
Packaged Length	15.50 IN
Packaged Width	10.50 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
