• Heavy gauge steel frame and base

Nameplate Specifications

Phase	1
Output HP	1/2 Hp
Output KW	0.37 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.25
Frame	48
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.4/2.2 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	N
CE	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	2
Rotation	Reversible Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Flat
Overall Length	10.59 in
Frame Length	7.13 in
Shaft Diameter	0.500 in
Shaft Extension	1.59 in

General Specifications

UPC	786674072429
Weight	25.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
