• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Continuous duty cycle design allows maximum operation at the rated power. specifications
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Capacitor start design optimizes motor torque and efficiency performance.

Nameplate Specifications

Phase	1
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	208-230/115 V
Speed	1725 rpm
Service Factor	1.15
Frame	P56HC
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	9.6-8.9/17.8 A
Duty	Continuous
Insulation Class	F
UL	No
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	14.21 in
Frame Length	8.00 in
Shaft Diameter	0.625 in
Shaft Extension	2.07 in

General Specifications

UPC	786674017031
Weight	32.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
