• Automatic thermal protection prevents overheating.
• Class B insulation protects motor for a maximum temperature rating.
• Double sealed bearing construction extends the lifetime of the motor.
• Totally enclosed air over, fully gasketed design.

Nameplate Specifications

Phase	1
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	230 V
Speed	850/725 rpm
Service Factor	1
Frame	P56CZ
Enclosure	Totally Enclosed Air Over
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60/50 Hz
Current	5.1/5.1 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Starting Method	Across The Line
Poles	8
Rotation	Counterclockwise
Mounting	Round
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	14.22 in
Frame Length	8.00 in
Shaft Diameter	0.625 in
Shaft Extension	3.25 in

General Specifications

UPC	786674016898
Weight	44.00 LB
Packaged Length	19.00 IN
Packaged Width	8.00 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
